D5D60-12GN-30S/5GN10K

  • Type:DC Brush Gear Motor
  • Model:D5D60-12GN-30S/5GN10K
  • Voltage: 12V 24V 36V
  • Speed(RPM): 3000RPM
  • Output Power:60w
  • Usage:Boat, Car, Electric Bicycle, Fan,Home Appliance
    • Hotline: 86-18802037981
    •              86-13570144285
    • Email:  faye@gzdmkemotor.cn
    •            shirley@gzdmkemotor.cn
Consult

Motor Performance Parameters

Type Power
W
Voltage
V
No-load Parameters Load Parameters Brush Life
H
Motor Weight
kg
Speed Current Speed Torque Current
r/min A r/min mN.m A
Z5D 40 12 3200 2.0max 3000 127 5.2 2000 1.9
40 24 3000 1.0max 2800 140 2.2 2000 1.9
40 90 3100 0.3max 2950 129 0.6 2000 1.98
60 12 3200 2.0max 2950 194 7.5 2000 2.2
60 24 3100 1.5max 2800 210 3.5 2000 2.2
60 90 3200 0.3max 3000 191 1.0 2000 2.2
90 12 3300 3.0max 2800 307 10.0 2000 2.2
90 24 3100 1.5max 2800 307 5.0 2000 2.2
90 90 3100 0.5max 2850 302 1.5 2000 2.2
120 12 3400 3.0max 3000 382 14.0 2000 2.2
120 24 3100 1.5max 2600 441 7.0 2000 2.2
120 90 3300 0.3max 3000 382 1.8 2000 2.2

Note: Above are only some typical models. For more information or a customized motor, Pls contact us.



Gearbox model:5GN∏K

The max allowable torque of the gearbox: 10.0nm

Transmission efficiency:gear ratio:3-18:81%, 25-36:73%, 50-200:66%

Dimensions (Unit: mm )

40w

Z5D 40w

60W

 Z5D 60w

90W

 Z5D 90w

120W

Z5D 120w
