brush gear motor Your Position: Home » Product Center

D55D250-24GN-30S dc motor

  • Type:DC Brush Gear Motor
  • Model:D6D250-24GU-32S
  • Speed(RPM): 3200RPM
  • Output Power:250W
  • Usage:Boat, Car, Electric Bicycle, Fan,Home Appliance
    • Hotline: 86-18802037981
    •              86-13570144285
    • Email:  faye@gzdmkemotor.cn
    •            shirley@gzdmkemotor.cn
Consult

Motor Performance Parameters

Type Power
W
Voltage
V
No-load Parameters Load Parameters Brush Life
H
Motor Weight
kg
Speed Current Speed Torque Current
r/min A r/min mN.m A
Z55D 250 24 3200 0.6max 2950 19 0.8 2000 0.6
250 90 3200 0.3max 2950 19 0.5 2000 0.6
250 220 3200 0.1max 3000 19 0.2 2000 0.6

Note: Above are only some typical models. For more information or a customized motor, Pls contact us.



Gearbox model:5GU∏KB(K)

The max allowable torque of the gearbox: 20.0nm

Transmission efficiency:gear ratio:3-9: 81%, 12.5-18:73%, 25-75: 66%,90-200: 59%

Dimensions (Unit: mm )

Z5D 250w.png
